| Brand Name : | Safety lock for suspended platform |
| Model Number : | ZLP630,ZLP800 |
| Certification : | CE,ISO |
| Price : | USD2100 |
| Payment Terms : | TT,LC |
| Delivery Time : | 5-7 days |
Professional Manufacturer Electrical Control Panel Board Made In China
Email: anicali@hrgondola.com
Suspended platforms are designed and constructed in modular form so it can be mounted in any size from 2-8 meters.
The connection of the individual parts of the structure in each unit is made with nuts and bolts.
The platform is equipped with wheels for easy movement around the construction site.
The working platform as bolt type and pin type.
Suspension mechanism of suspended platform
With hot galvanized steel,the suspension mechanism uses 80*80,70*70 square tube, thickness is 3.75mm, front and rear girder is 2.35mm thickness, middle girder is 2.48mm, thickness of working platform is 2.2mm.
Hoist of suspended platform
With famous brand of motor, large braking torque, unique anti-rope clamping device, when the rope is clamped,the alarming rings,the motor stops working, so that factor of safety is increased meantime, maintenance cost of hoist is reduced. Lubrication oil is 220# industry gear oil.
Safety lock of suspended platform
The lock cylinder uses special stainless steel, with strong impact resistance, higher toughness, wear resistant, long services life,safe and reliable.
Electric control box
The electric components uses CHNT,SCHNEIDER brand, reliable quality,easy to maintain.
Specification of suspended platform
Item | ZLP630 | ZLP800 | ||
Rated load | 630kg | 800kg | ||
Lifting speed | ~9.5m/min | ~8.5m/min | ||
Platform size (length×width×height) | (2000*3)*690*1180mm | (2500*3)*690*1180mm | ||
Suspension mechanism | Front beam extension | 1.1m-1.5m | ||
Height adjustment | 1.45m-1.75m | |||
Hoist | Type | LTD63 | LTD80 | |
Motor | Type | Customization | Customization | |
Power | 1.5KW | 2.0KW | ||
Voltage | 380V | 380V | ||
Speed | 1400n/min | 1400n/min | ||
Braking torque | 15N·m | 15N·m | ||
Safety lock | Type | LS30 | ||
Angle of tilted locking rope | 3°—8° | |||
Allowable impact force | 30kN | |||
Weight | Working platform | 300kg | 370kg | |
Hoist | 52kg×2 | 56kg×2 | ||
Safety lock | 5.5kg×2 | 5.5kg×2 | ||
Suspension mechanism | 320kg | 320kg | ||
Electricity box | 18kg | 18kg | ||
Total weight | 812kg | 872kg | ||
Counter weight | 1000kg (25×40pieces) | 1000kg (25×40pieces) | ||
Wire rope | Type | 4×31SW+FC-ф8.3 | 4×31SW+FC-ф8.3 | |
Cable | Type | 3×2.5+2×1.5YC-5 (one piece) | ||
|
|
